Panel Benders · LHA-XC series

Multi-Axis XC Panel Benders

An 11-axis compact bending center combining suction-cup handling with added synchronized motion for more flexible forming.

LHA-1000XCLHA-1400XC

Configure this platform Email an engineer

Representative configuration shown. Tooling and handling are tailored to the application.

11-axisSynchronized control

1000 / 1400 mmWorking widths

0.2 secFastest bend

1.2–1.6 kWAverage power

Platform overview

Built around the workpiece and the production goal.

The XC series builds on the compact suction-cup format with 11 synchronized axes and 1000 or 1400 mm working widths. It is engineered for automatic positioning and repeatable forming of small to medium parts.

Low average power, a compact machine envelope and optional powered horn tooling make the range well suited to growing fabrication cells.

11-axis coordination

Additional synchronized motion supports accurate positioning and more flexible forming sequences.

Two compact sizes

Choose a 1000 or 1400 mm working width around the part envelope and available floor space.

Suction-cup handling

Automatic vacuum feeding reduces manual part positioning for repeat production.

Optional horn tooling

A powered horn blank holder can be configured for the required product and edge-forming geometry.

Machine gallery

A closer look at the platform.

Technical overview

Representative specifications.

Final capacity and dimensions depend on material, thickness, tooling, bend geometry and automation scope.

Specification	LHA-1000XC	LHA-1400XC
Maximum bending width	1000 mm	1400 mm
Maximum bending size	1000 × 1000 mm	1400 × 1400 mm
Bending height	170 mm	170 mm
Maximum bending speed	0.2 second/time	0.2 second/time
Average power	About 1.2 kW	About 1.6 kW
Machine size	285 × 150 × 280 cm	365 × 190 × 290 cm
Approximate weight	7 t	10 t
Axis quantity	11	11
